Description

• 20A v2: Hobbywing Skywalker 20Amp V2 Brushless ESC This high functionality Electronic Speed Controller turned into specially designed for air functions to maximize their prospective performance Features a excessive performance 32-bit microprocessor with a operating frequency of up to 96MHz, DEO (Driving Efficiency Optimization) technology that drastically improves throttle response and using efficiency and reduces ESC temperature This Skywalker ESC also is geared up with typical and reverse brake modes that will effectively shorten the touchdown distance for the aircraft and a seek mode may also help users find the plane through the alarm beeps after the aircraft falls into a complicated surroundings Get your Skywalker ESC and journey excessive performance and performance with many protection aspects to keep your electronics safe and ready to get your planes airborne! Specifications:Model: 20A V2Input Voltage: 2-3SBEC Output: 5V @ 3A (Linear-mode)Continues Current: 20APeak Current: 40ADimensions: 45x23x8mm (LxWxH)Weight: 19gWire Input: 16AWG-100mmWire Output: 18AWG-75mmOutput Connectors: 3 Bullets (Female) 30A: Constant Current: 30A Peak Current:40A(10s) Voltage: 2-3S lixx BEC: Yes BEC Output: 5V/2A Color: black Programmable:Yes Size: 70*25*8mm (not including cable length) Net Weight:38g 40A: Model: Skywalker-40A Continuous Current: 40A Burst Current (>10s): 55A BEC Mode: Linear BEC Output: 5V2A BEC Output Capability: 5 Servos (2S Lipo) / four Servos (3S Lipo) Battery Cell: 2-3S (Lipo) / 5-9 cells (NiMH) Net Weight: 35g Dimension (L x W x H): sixty eight x 25 x 8mm here's the previous version,it do not include golden bullet connectors,please consider about it 50A: COntinuous output: 50A Burst current: 60A@10S Power input: 2-4S Lixx/5-12S Nixx 5V/3A BEC output, change mode Refresh rate: 50Hz-432Hz Max speed: 2-Pole 210000rpm/min; 6-Pole 70000rpm/min; 12-Pole 35000rpm/min Dimension: 68*25*12mm Weight: 43g 60A: Item Name: Hobbywing SkyWalker 60A UBEC ESC Constant Current: 60A Burst Current (>10s): 80A BEC Mode: change mode BEC Output: 5V at 3A Battery Cell: 2-6 cells Lipo,or 5-18 cells NiHH Refresh Rate: 50Hz-432Hz Dimension: seventy seven x 35 x 14 mm Weight: 60g Maximum speed: 210000 RPM (2 poles motor), 70000 RPM (6 poles motor), 35000 RPM (12 poles motor) 80A: Item Name: SkyWalker 80A UBEC Type: Brushless ESC,Regular voltage Cont/Peak Current: 80A/100A Input: 2-6S LiPo,5-18s Ni-MH BEC Output: Switch Mode--5V,5A Input Wires: Red-12AWG-150mm*1,Black-12AWG-150mm*1 Output Wires: Black-14AWG-100mm*3 Input Connectors: NO Output Connectors: NO ESC Programing via: Transmitter,LED Program Card,Program Port (Program/Throttle Wire) Firmware Upgrade: Not Supported Size: 86 Weight: 82g

•
•
•
•
•
