Description

• With 1A bridge rectifier, the regulator device makes use of 7805/7806/7809/7812/7815/7818/7824, and the input is 2 4 70uF filter electrolytic capacitor, filtered in two stages, the output using 220uF capacitor, appropriate for 35V power supply appliances, equipment, audio and so on, to provide low inside resistance, low ripple, low EMC interference energy supply Custom 5V, 6V, 9V, 12V, 15V, 18V, 24V output voltage could be personalized for customer support The electrolytic capacitor of the ability supply is a home real capacitor, there are several brands, before capturing can consult the logo of the electrolytic capacitor used Before using the board, be certain that the output voltage of the power transformer you are using, in addition the range of energy delivery fluctuations, reserves a certain amount of voltage margin Product Parameters Dimensions: 43mm long, 23mm broad and 25mm excessive Input voltage: Output DC voltage 5V, 6V, 9V, 12V, 15V, 18V, can be entered as much as AC voltage 22V Output DC voltage 24V, would be entered as much as AC voltage 24V Output current: ≤ 600mA, the bigger the enter and output strain difference, the smaller the output recent Wiring AC is the input AC side, despite right or unhealthy The V-output DC is high quality and the GND output DC is destructive

•
•
•
•
