Description

• General ERV-XX timer relay are utilized in all fields (industry, house, plant etc) need controlls related to the time Usage and Working Principle Please make the connection in step with the diagram Please alter the delaying time by the button Energize the system Device will depend the stand via time On(Power) led will get on when the counting occurs, Out(relay) led will get off During this step touch output is (NC)1 After the time is up Out (relay) led gets on and phone output is (NO)3 Until it is de-energized machine remains the same Maintenance Switch off the machine and release from connections Clean the trunk of gadget with a swab Don’t use any conductor or chemical may possibly damage the system Make sure gadget works after cleaning Warnings Please use the system in step with the guide Don’t use the machine in moist Include a switch and circuit breaker within the assembly Put the change and circuit breaker close by the device, operator can reach easily Mark the swap and circuit breaker as liberating connection for system Specifications Operating Voltage(Un): 150V-260V AC/24VDC or 110VAC/24VDC Operating Frequency: 50/60 Hz Operating Power: <4VA Operating Temperature: -20°C+55°C Time(t): zero Display:: On led and Out led Connection Type: Terminal connection Weight: Max Contact:5A/250V AC (Resistive Load) Mounting: Vertical assembled in the panel or assembled at the din rail Operating Altitude: <2000meter Cable Diameter: 2,5mm² Working Mechanism Dimensions Connection diagram

•
•
•
•
•
